Main hardware indicators | |
size | L45mm x W45mm x H3.0mm |
CPU | Allwinner T507 quad-core clocked at 1.5GHz |
GPU | Mali-400 G31 GPU |
RAM | LPDDR4 standard 2G (1G/4G batch optional) |
memory | eMMC standard 8G (16G/32G/64G batch optional) |
power management | AXP853T supports standby, key switch |
Operating Voltage | The input voltage is 5V and the maximum power is less than 2W (without any peripherals) |
support system | Android/Linux+QT |
operating temperature | -40 to +85 degrees Industrial grade |
life | Continuous operating life is more than 5 years |
Common interface of core board | |
USB interface | 4 independent channels, one of which is OTG |
UART serial port | 6 channels of TTL 3.3V level, one of which is Debug |
GPIO interface | 98 GPIOs (Note: with multiplexing function) |
PWM interface | 6-channel PWM 3.3V level (Note: with multiplexing function) |
LVDS display | 1 channel LVDS maximum support 1920x1080 1080P 60fps |
RGB display | 1 channel RGB 888 output, maximum support 1920x1080 1080P 60fps |
HDMI display | 1 HDMI output supports 4K 60fps output |
CVBS output | 1 CVBS output |
voice output | 1 channel left and right channel output, 5W power amplifier attached to the bottom plate |
CAN bus | 1 CAN BUS 2.0 bus |
SDIO interface | 2 SDIO interfaces, one TF card, the other connected to WIFI |
ADC interface | 2-channel ADC interface |
I2C interface | 5-way I2C interface |
SPI interface | 1 way SPI interface |
Ethernet | Dual Ethernet, GMAC and EMAC PHY interfaces |
output power | Multi-channel power output 1.8V 3.3V |
System Upgrade | Support local USB upgrade |
CORRENT PARAMETER TABLE
project | minimum | typical | maximum | |
Power parameters | Voltage | 4.5V | 5V | 5.5V |
ripple | -- | 50mV | 120mV | |
current | 235mA | -- | -- | |
supply current (No other peripherals connected) | Turn-on current | 247mA | 369mA | 720mA |
Play sound | 265mA | 345mA | 565mA | |
supply current (connected to the display) | ||||
environment | Relative humidity | -- | 65% | 75% |
Operating temperature | -40℃ | -- | 85℃ | |
storage temperature | -50℃ | 0℃ | 100℃ | |
Main hardware indicators | |
size | L45mm x W45mm x H3.0mm |
CPU | Allwinner T507 quad-core clocked at 1.5GHz |
GPU | Mali-400 G31 GPU |
RAM | LPDDR4 standard 2G (1G/4G batch optional) |
memory | eMMC standard 8G (16G/32G/64G batch optional) |
power management | AXP853T supports standby, key switch |
Operating Voltage | The input voltage is 5V and the maximum power is less than 2W (without any peripherals) |
support system | Android/Linux+QT |
operating temperature | -40 to +85 degrees Industrial grade |
life | Continuous operating life is more than 5 years |
Common interface of core board | |
USB interface | 4 independent channels, one of which is OTG |
UART serial port | 6 channels of TTL 3.3V level, one of which is Debug |
GPIO interface | 98 GPIOs (Note: with multiplexing function) |
PWM interface | 6-channel PWM 3.3V level (Note: with multiplexing function) |
LVDS display | 1 channel LVDS maximum support 1920x1080 1080P 60fps |
RGB display | 1 channel RGB 888 output, maximum support 1920x1080 1080P 60fps |
HDMI display | 1 HDMI output supports 4K 60fps output |
CVBS output | 1 CVBS output |
voice output | 1 channel left and right channel output, 5W power amplifier attached to the bottom plate |
CAN bus | 1 CAN BUS 2.0 bus |
SDIO interface | 2 SDIO interfaces, one TF card, the other connected to WIFI |
ADC interface | 2-channel ADC interface |
I2C interface | 5-way I2C interface |
SPI interface | 1 way SPI interface |
Ethernet | Dual Ethernet, GMAC and EMAC PHY interfaces |
output power | Multi-channel power output 1.8V 3.3V |
System Upgrade | Support local USB upgrade |
CORRENT PARAMETER TABLE
project | minimum | typical | maximum | |
Power parameters | Voltage | 4.5V | 5V | 5.5V |
ripple | -- | 50mV | 120mV | |
current | 235mA | -- | -- | |
supply current (No other peripherals connected) | Turn-on current | 247mA | 369mA | 720mA |
Play sound | 265mA | 345mA | 565mA | |
supply current (connected to the display) | ||||
environment | Relative humidity | -- | 65% | 75% |
Operating temperature | -40℃ | -- | 85℃ | |
storage temperature | -50℃ | 0℃ | 100℃ | |
